Part 1 of 3: Defining the needle and the haystack

Finding the right location for an infrastructure project means solving a multidimensional optimization problem where all the variables interact in complex ways. How much does grid power price matter compared to land cost? What about solar availability? How do you weigh transportation infrastructure against the regulatory environment? How do you move fast, while also meeting your critical economic and sustainability goals?

The traditional approach involves firing up GIS tools, gathering data, and trying to filter through data layers with different time periods, formats, etc. This can include factors such as electricity prices, infrastructure maps, land costs, renewable resource maps, and many, many more. Maybe you have a secret sauce, but I bet you’ll miss hidden gems - the sites that aren't obviously attractive but deliver exceptional economics when all factors are considered together.

We've been working on a different approach: searching based on the characteristics of an individual location AND how all of those factors come together into the north star for most developers, operators, and financiers - the ROI of your project (NPV, IRR, LCOE, or whatever metric means success for you).

This article will first talk about the challenges of our initial approach for modelling hydrogen production costs. We’ll then describe our new approach: allowing users to upload their own project economic models to be run on our data platform. To wrap up, we’ll outline the next two blog posts: how we execute user provided economic models on our GPU-accelerated optimizer, to find the perfect sizing and configuration for your project; and finally, how we use neural networks to run your optimized economic model over the whole globe, allowing you to find your needle-in-a-haystack with a simple search.

‍

The hard-coded model problem

When we built our first tool, for hydrogen project siting, we took what seemed like a reasonable approach: we built a comprehensive LCOH (Levelized Cost of Hydrogen) model that captured all the key economic factors and allowed users to customize the variables that mattered most.

Users could adjust numerous factors including:

• Equipment costs and capacity factors
• Financing terms and discount rates
• Hourly offtake profile over a year
• Production efficiency curves

The system would then calculate LCOH and IRR for any site using our hardcoded model structure. It worked well for standard projects, but we kept hitting the same wall: users wanted to modify the model itself, not just the inputs. We also wanted to expand our platform to projects other than hydrogen production, such as data centers.

We realized we were solving the wrong problem. Instead of building increasingly complex configuration options for our hardcoded model, we needed to let users bring their own economic models entirely.

‍

The Excel template approach

The solution turned out to be surprisingly straightforward: let users upload their own Excel models.

We created an Excel template that defines the interface between user models and our geographic data. Users can either customize one of our provided models or build their own from scratch. The template handles the data injection - our system knows how to feed location-specific data into the designated cells, and the model handles everything else.

This approach preserves the sophistication of user models while enabling them to run anywhere in the world using our data platform. Your carefully crafted depreciation schedules, custom financing structures, and cost models all work exactly as designed - dynamically fed with real-world data.

‍

How our tool works

The process is simple:

1. Upload your Excel model (or customize one of ours)
2. Select any location from our global dataset of over 180 million sites
3. Get instant model results for that site

Behind the scenes, when you click on a site in, say, Wyoming, or Bavaria, our system instantly injects our rich datasets for that location, including:

• Hourly electricity prices from the local grid operator in US and Europe (annual elsewhere, for now)
• Wind and solar resource data at hourly resolution
• Natural gas pipeline access and pricing
• Land costs and availability
• Grid interconnection requirements and costs

Your Excel model processes this data exactly as it would with any other inputs, but now it's using real-world, location-specific information saving you the trouble of finding the data or the dangers of generic assumptions. The power of this is also in the comparative view, so rather than just evaluating one site to see if it clears your viability hurdles, you can evaluate any site to find the strongest option. Choose exceptional, rather than just acceptable.

You can export your model with these values injected, or browse the data within our Explorer tool. (You can also click to run our GPU-accelerated optimizer, but that’s for the next blog post.)

‍

Multiple project types, multiple configurations

The complexity multiplies when you consider that you're not just searching for locations—you're searching for the optimal combination of location, project configuration, and operational parameters.

For hydrogen production, you might be evaluating:

• Different production methods (electrolysis, steam methane reforming, pyrolysis)
• Various power supply configurations (grid, solar, wind, hybrid)
• Multiple operational scenarios (capacity factors, maintenance schedules)

For data centers:

• Different compute workloads (CPU vs GPU intensive)
• Various power supply options (grid, renewables, backup systems)
• Different cooling strategies and their associated costs

Each combination creates a different economic profile, and the optimal choice varies by location. A site that's perfect for a GPU-intensive data center with solar power might be terrible for a CPU-focused facility relying on grid electricity.

Our Excel template lets you easily define these various options and, on choosing a particular site, our tool will run your model for every such option for you to then browse within our tool - or export back as an Excel file.

‍

What's coming next

This Excel integration solves the flexibility problem—users can now bring their own sophisticated models and run them anywhere. But it doesn't solve the search problem.

In our next post, I'll walk through how we run your Excel models on our cloud-based GPU-accelerated optimizer. Rather than spend thousands of developer hours converting models for linear optimizers, take your Excel-based non-linear model and just throw powerful GPUs at it. Our technology is able to combine gradient descent with particle swarm optimization over millions of particles for truly exceptional results - out of the box.

The third post will cover something even more ambitious: training custom neural networks to approximate your optimized models. This is how users of our hydrogen product are able to search the globe based on factors including pre-optimized LCOH, and what we are now enabling on a fully custom basis. Once we have a neural network that can mimic your Excel model's optimized behavior, we can run it at every potential site worldwide, across all possible configurations, in a matter of minutes. This creates a true global search capability - the ability to find exceptional opportunities in a sea of merely acceptable options.

‍

The bigger picture

What we've built is a fundamental shift in how infrastructure projects get sited. Instead of searching based on individual factors and hoping they combine favorably, you can search based on actual economic performance. Instead of evaluating a handful of obvious sites, you can systematically explore millions of possibilities.

Your Excel model represents deep domain expertise about your specific project economics. Our platform just helps that expertise engage with the full complexity of global geography and energy markets. The results can be surprising - sometimes the best location for your project is one you never would have thought to evaluate.

‍

Hi, I’m Jules Carney! As a front-end engineer at Othersphere, I’ve had the chance to work on features that would have felt impossible to bring to the web even a few years ago. We bring together detailed, accurate data from across the globe, and use it to paint a picture with graphs, maps and other visualizations. It brings insights on potential sites that tell meaningful stories for any audience. Needless to say, working on these features is a web developer’s dream come true!

Today I’ll walk through one of my favourite feature sets, because it imparts so much info about a potential site that users looking for a site could feel like they’re on the ground with their measuring tapes.

For a full video of the walkthrough below, please click here!

Let’s say a team wants to build a data center near Boulder, Colorado, but is worried about how the landscape will fit in with their building designs.

First, we’ll make a stop at the main map, where we can filter based on attributes we want the site to have, like average slope, land cost, distance to roads or power sources, and many other crucial factors. In the picture below, we’ve filtered to return sites with only 0-5% built area, and are colouring our heat map based on topography. Less populated areas tend to have steeper slopes, but with just this three second search we see some pale yellow hexes which are nice flat sites with few built-up areas. We could also do another search including our slope requirement filters if we wanted to just get back the hexes with lower slopes.

‍

After we’ve picked a site, we can jump into site analysis. Looking at the left-hand tabs, we can see many ways to evaluate our location, including factors relating to economics, emissions, and fit with local human and environmental factors. These factors are then rolled into detailed project modeling, to bring the whole story together.

But let’s assume that the fundamentals look good, and so we want to move to the footprint tab as concern becomes fitting our data center to a given site.

First we check out a site, and we have a good sized potential footprint to work with, close to high voltage powerlines and data transmission cables.

‍

Let’s assume we want to build a site about 1km square, so we check out an area with our Measure area tool.

‍

It looks decent, and not built up, but let’s dig into the elevation and landscape a little more. We draw a line to measure the distance of our potential site, and we also get an elevation profile, which reveals a pretty significant variation of over 20 metres.

‍

This area looks more promising! We see less variation in the elevation profile.

‍

When we check out the area, it looks like there will be ample space here.

‍

As a project developer I’d likely now loop back to iterate on the project model, using this area analysis and all of our other data to fine tune potential cost, emissions, and planning for aspects of local fit such as protected areas. From there I would likely review details on the land parcels and owners, to get ready for external engagement.

By bringing all of this together in one place, we can pick a great site with no surprises and everything we need for our data center to succeed!
